The HP 78660A/B Defibrillator is a
full featured Defibrillator/Monitor/Recorder designed
for use in hospitals as well as ambulances. It
combines a 360 Joule defibrillator, ECG monitor and
annotating strip chart recorder in a compact
lightweight package. The 78660B has interchangeable
paddles.
SPECIFICATIONS:
Delivered Energy: 360 joules into a 50 ohm load
Waveform: Damped sinusoidal output pulse
Charging Time: Less than 10 seconds to full
charge
Battery: Supplies 50 full energy charges or 2.5
hours of monitoring.
Synchronization: Accepts signal from paddles or
lead wires
Power: 110-130, 200-250VAC, 50/60Hz, 250VA
Weight: 12.2kg (27 lb.) (Defibrillator only)
Size: 22.9cm high,31.1cm wide, 47cm deep
(9x12.25x18.5in.)
* Power base included
|
