DRE ASG-200 Electrosurgical Generator

DRE ASG-200 ELECTROSURGICAL GENERATOR


DESCRIPTION

CONDITION

SUGGESTED RETAIL

INTRODUCTORY
PRICE

WARRANTY

DRE ASG-200 Watts electro-surgical unit - digital technology for all surgery except cardiac

New

$4,960.00

$4,460.00

2 years

The DRE-200 ESU units use dedicated digital hardware instead of a general purpose controller for processing data. This hardware allows parallel data processing and generates very high data processing throughput, measuring tissue impedance 5000 times per second. All data is sampled and processed digitally, being converted to analog only in the output stage.

This digital technology will make controlling the ASG system very simple for the OR team during any point of the procedure, allowing the surgeon to concentrate on what’s important – the operation and the patient.

Features Overview:

Power - 200 watt maximum output generator designed for any and every cautery or surgical procedure. IDS technology gives the surgeon the flexibility to consistently choose the type of effect he desires with maximum convenience and safety.

Cutting - The ASG-200 is equipped with a digitally controlled and regulated cutting effect. This innovative cut behavior can be utilized in a variety of procedures, from high-powered / high-impedance procedures (CUT I) to general applications (CUT II). Blended Cutting Mode with 10 blend settings.

Cut Mode – has a digitally controlled cutting quality that ensures performance when cutting adipose tissue or cutting underwater with minimal output power. The cut is precisely controlled by the unit.
Blend Mode – 10 blend settings in 6% increments combines cut and coag in a way that allows for greater flexiblity and customization. Maximum blend adjustment is 60% coag, 40% cut.

Coagulation – The ASG-200 Coagulation technology performs Monopolar, Pinpoint and Spray, and Bipolar. The coagulation technology performs Monopolar and Bipolar Coagulation effectively in every type of tissue and a variety of procedures. Digitally controlled Monopolar Coagulation effects include Pinpoint, a rapid desiccation effect without carbonization and less sticking of the electrode; and Spray, a slight penetration of the tissue surface which is very efficient for treatments like diffuse bleeding or tissue devitalization. In Bipolar Coagulation the digital technology reduces active electrode sticking by minimizing tissue carbonization.

Pinpoint - Coagulation Mode delivers a digitally controlled rapid desiccation effect without carbonization and less sticking of the active electrode.
Spray - Coagulation Mode gives digitally controlled non-contact coagulation with a slight penetration of the tissue surface – very efficient for treatments like diffuse bleeding or tissue devitalization.
Bipolar - Coagulation Mode also uses digital technology to reduce instrument sticking and to minimize tissue carbonization.

Surgeon’s Preset Center – A preset center allows up to 10 surgeons to store their preferred power settings in the Cut, Coagulation, and Bipolar Modes.

Footswitch Indicator – A display on the front of the generator clearly indicates if one or two footswitches are connected, and to which outputs.

Safety - The ASG-200 Electrosurgery unit is digitally designed and has a variety of safety features built in. Bovie FDFS™ (Fast Digital Feedback System) – The digitally controlled CUT and COAG functions give a consistent clinical effect. Bovie NEM™ (Neutral Electrode Monitoring), Bovie FCFS™ (First Come First Served) – Discrete output design allows only one output device to be activated at any given time. Bovie DED™ (Digital Error Detection) – Unsurpassed safety for the surgeon, OR staff, and patient. At the sign of any problem, the unit instantly disables the output and displays the appropriate error code.

Plug & Play – The ASG-200 is ready to use: plug in the instrument; start to work. Calibration Free – The ASG-200 does not need any calibration due to its digital technology.

Specifications

OUTPUT POWER
Cut - 200 W @ 300 O
Blend - 200 W @ 300 O
Pinpoint - 120 W @ 500 O
Spray - 80 W @ 500 O
Bipolar - 80 W @ 150 O
Duty Cycle - 10 S / 30 S
OUTPUT FREQUENCY
490 kHz ± 5
INPUT CURRENT
4.5 A ~
LINE VOLTAGE
100 - 240 V ~
LINE FREQUENCY
50-60 Hz
WARRANTY
one year

Optional Accessories

BiPolar Footswitch required for BiPolar operation.
Monopolar Footswitches
Pens / Pencils
Grounding Pads

Depending on Availability / Shipping Charges Not Included
